Known as our “Heart of the Line”, the 2200-2400 series offers a full range of features that meet the needs of most industries today. Available in both 2 and 4 wheel drive, this model of forklift was designed around the operator and includes unparalleled visibility and modern machine ergonomics. Advanced vibration and sound deadening technologies were used during the design process to provide quiet, smooth performance. A full range of C-Thru masts is offered giving this series a wide range of applications.
| Industry leading visibility and sight lines |
| Large operators compartment |
| Generous leg and foot room |
| Excellent operator access on and off machine |
| Adjustable tilt steering column |
| Solid state, L.E.D. instrument cluster |
| Adjustable seat height from the operators position |
| Fast, responsive hydraulic controls |
| Finger tip steering even at low engine idle |
| Componentized power train |
| Limited slip differential |
| Hydraulic oil immersed disc brakes |
| Quieter operation due to increased insulation and anti-vibration technology |
| Extremely tight turn radius |
| Available in two & four wheel drive |
| Full range of C-Thru masts |
| 6,000 to 20,000 LB capacity |
| Lift Heights to 30 Feet |
| Roomy well equipped optional cab assembly |
| Powder coated for a true life time finish |
| Available with full factory R.O.P.S. Cab certification |
| Available with factory U.L.C. DS certification |
| 6,000 LB Capacity | 8,000 LB Capacity | 10,000 LB Capacity | 12,000 LB Capacity | 15,000 LB Capacity | 18,000 LB Capacity | 20,000 LB Capacity | |
| Capacity (lbs) | 6,000 | 8,000 | 10,000 | 12,000 | 15,000 | 18,000 | 20,000 |
| Engine Type | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel |
| Max Lift Height (Raised) | Available Upon Request | – | – | – | – | – | – |
| Overall Width (in) | 84″ | 84″ | 84″ | 84″ | 91″ | 100″ | 100″ |
| Overall Length (in) | 152 1/4″ | 152 1/4″ | 152 1/4″ | 156 1/4″ | 174″ | 192 1/2″ | 192 1/2″ |
